Cantilever U Spring Energizer

The main difference is their profile geometry and resulting load-deflection behavior. For comparable designs made from the same material and with the same nominal dimensions, Handa’s U spring can provide higher spring load and a more stable load response over a wider deflection range than the corresponding V spring. Actual performance depends on the selected profile and working conditions.

Key parameters typically include spring height, width, strip thickness, profile geometry, installed deflection, and finished configuration. A drawing or sample is the best starting point. If the design is still being developed, provide the target load and available installation space.

Yes. Handa Spring supports custom U spring profiles and dimensions. Depending on the required changes, manufacturing may use an existing profile and tooling, modified tooling, or newly developed tooling.

Material options depend on the spring profile, strip dimensions, supply condition, and application requirements. Stainless steels and selected high-performance alloys can be evaluated according to the required spring properties, corrosion resistance, and operating environment.

Load-deflection testing can be used to verify spring performance against agreed requirements. Please specify the target load, measurement point or working deflection range, and any applicable acceptance criteria when requesting a quotation.
